DESCRIPTION

KEF’s First THX® Certified Dominus In‑Wall Speaker

The Ci5160REFM‑THX represents the pinnacle of KEF’s architectural engineering — the first in‑wall loudspeaker to achieve THX® Certified Dominus, the highest and most demanding performance class in the THX® system. Designed for large home theatres and expansive living spaces, it delivers breathtaking realism, precision, and scale while remaining visually discreet.

Powered by KEF’s latest 12th‑generation Uni‑Q® driver array with MAT™, this reference‑grade in‑wall speaker produces an immersive soundstage with exceptional clarity and detail.

Realistic, High‑Fidelity Sound

The Ci5160REFM‑THX features four 160mm (6.5‑inch) bass drivers engineered specifically for in‑wall performance. The result is:

  • Deep, articulate bass down to 32Hz

  • Clean, controlled low‑frequency extension

  • A massive, vented motor system for effortless dynamics

  • A seamless, room‑filling soundstage

This is architectural audio without compromise.



SPECIFICATION

Nominal Impedance

  • 4 Ω

Sensitivity (2.83V/1m)

  • 92dB

Frequency Performance

  • Frequency response (±6dB), open‑backed: 40Hz – 28kHz
  • Frequency range (‑10dB): 32Hz – 45kHz

Nominal Coverage

  • 150°

Crossover

  • Crossover frequencies: 600Hz, 3000Hz

Drive Units

  • LF: 4 × 160mm (6.5 in.)
  • MF: 125mm (5.25 in.) Uni‑Q
  • HF: 25mm (1 in.) vented aluminium dome with Metamaterial Absorption Technology

Amplification

  • Recommended amplifier power: 50 – 500W
  • Recommended high‑pass filter: 35Hz – 80Hz

Dimensions

  • Product external dimensions (H × W × D):
    1070 × 230 × 105.7 mm (42.13 × 9.06 × 4.16 in.)
  • Cut‑out dimensions (H × W):
    1052 × 209 mm (41.42 × 8.23 in.)
  • Mounting depth from surface:
    99 mm (3.9 in.)

Weight

  • Net weight: 21.7 kg (47.8 lbs.)

Installation

  • Optional rough‑in frame: RIF5160L
  • Wall thickness (maximum): 40 mm (1.58 in.)
  • Wall thickness (minimum): 6 mm (0.24 in.)

Performance

  • Maximum SPL: 116dB
  • Certification: THX® Certified Dominus

Remarks

  • Metamaterial Absorption Technology is a joint development with Acoustic Metamaterials Group.
  • KEF reserves the right to amend specifications in line with ongoing research and development.
  • THX, the THX logo, and Ultra are trademarks of THX Ltd.
