LCR300

The Waterfall Audio LCR300 from the Pro Custom Series is a high-performance in-wall speaker designed for dedicated home cinema rooms. With a depth of 21 cm (8 1/4"), it seamlessly integrates behind acoustically transparent screens, delivering powerful and precise audio without compromising space.

Featuring a 3-way closed design, the LCR300 is equipped with two 150 mm (6") Atohm LD150 bass drivers, one 150 mm (6") Atohm LD150 midrange driver, and a 20 mm (0.75") Atohm SD20 soft dome tweeter. This configuration ensures a wide frequency response from 80 Hz to 28 kHz, providing detailed and dynamic sound reproduction suitable for rooms ranging from 25 to 50 m².

With a peak power handling of 500W and an efficiency of 91 dB, the LCR300 delivers immersive audio experiences, whether used as a Left, Center, Right (LCR) speaker or as surround speakers in larger setups.

• Pro Custom Series

• Depth: 21 cm (8 1/4")

• Color Available: Black

• Article Code: A052PCSLCR2

• High-Performance Drivers: Equipped with Atohm LD150 and SD20 drivers for precise sound reproduction.

• Versatile Application: Suitable for LCR or surround configurations in various room sizes.

• Robust Construction: Designed for integration behind acoustically transparent screens.

• Made in France: Crafted with precision and quality materials.

  📐 Technical Specifications:

  • Type: 3-way, 4 drivers, closed design

  • Recommended Amplifier Power: 100 – 300W

  • Peak Power Handling: 500W

  • Impedance: 8 / 4 Ohms

  • Efficiency: 91 dB (2.83V/1m)

  • Frequency Response: 80 Hz – 28 kHz (±3 dB)

  • Bass Drivers: 2 x 150 mm (6") Atohm LD150

  • Midrange Driver: 1 x 150 mm (6") Atohm LD150

  • Tweeter: 1 x 20 mm (0.75") Atohm SD20

  • Dimensions (W x D x H): 570 x 204 x 430 mm (22.44" x 8.03" x 16.93")

  • Weight: 17 kg (37.4 lbs)
